Do not discard the hardware bags or mix parts from
different bags. Make note of the symbol printed on
each hardware bag. The symbols can be used to
identify the appropriate hardware for each step.
We recommend that you pull everything out of the box and lay it out. We have
grouped the drawn components below with the hardware you’ll need for those
parts. The screws below are drawn to scale to make it easier to identify what
piece of hardware is needed to install each component.
x4
x2
x2
x2
For installing the hanger bracket and wiring the fan
For installing the canopy
Canopy
Canopy Screw
Ceiling Bracket
Wood Screw
Wire Nut
Washer
bag
Hunter Pro Tip:
Find a part that is missing or damaged?
Don’t take it back to the store. Let us make it right. Visit us at HunterFan.com or call us at 1.888.830.1326.
Here is what comes in your box:
bag
For installing the blades
For installing the light kit
Motor
Light Kit
Downrod
M4010-01 r032723
Fan style may vary.
Note:
For your convenience,
you may receive extra fasteners.
bag
Glass
x7
Blade
Upper Switch Housing
Blade Medallion
Blade Iron
x7
x7
x21
bag
Blade Screw
x14
bag
Blade Iron Screw
Remote Components
Remote Control
Light Kit Screw
x3
x3
bag
Short Light
Kit Screw
To Next Page
