Lift the lower switch housing until its screw holes are aligned
with the screw holes in the blade irons. Install the three
assembly screws, found in the hardware bag . Tighten
all three screws.
Lift the cap and attach to the switch housing plate using
magnet found in hardware bag . Cap will snap to place
magnetically.
3 of 3
Assembly Screw
Magnet
bag
bag
