Do not discard the hardware bags or mix parts from
different bags. Make note of the symbol printed on
each hardware bag. The symbols can be used to
identify the appropriate hardware for each step.
x2
x2
x2
x2
For installing the hanger bracket and wiring the fan
For installing the blades
For installing the canopy
For installing the light xture
bag
Hunter Pro Tip:
Find a part that is missing or damaged?
Don’t take it back to the store. Let us make it right. Visit us at HunterFan.com or call us at 1.888.830.1326.
bag
Bulb
Glass
Globe Retainer
Finial Cap
Finial
Lower Switch Housing
Motor
Blade
Canopy
Canopy Screw
Wood Screw
Washer
Small Flat Head Screwdriver
x3
bag
Light Kit Screw
Fan style may vary.
Note:
M0285-01 r062623
x5
We recommend that you pull everything out of the box and lay it out. We have
grouped the drawn components below with the hardware you’ll need for those
parts. The screws below are drawn to scale to make it easier to identify what
piece of hardware is needed to install each component.
Here is what comes in your box:
For your convenience,
you may receive extra fasteners.
Pullchains
bag
Receiver
Ceiling Bracket
To Next Page
