Huntron TRACKER 2700 - Page 114

7-
13
Pin 2 -Input Pin 3 +Input Pin 6 Output
10V, 100Ω
ΩΩ
Ω Range
Figure 7-12. Signatures Of An Op Amp (741 Type), Common to Pin 4
Pin 2 -Input Pin 3 +Input Pin 6 Output
15V, 10 kΩ
ΩΩ
Ω Range
Figure 7-13. Signatures Of An Op Amp (741 Type), Common to Pin 4
