REPAIR PARTS
TRACTOR - - MODEL NO. 12592RB (BA12592RBC), PRODUCT NO. 964 77 93-00
CHASSIS AND ENCLOSURES
1 532 17 46-20 Chassis
2 532 18 03-84 Drawbar
3 817 06 06-12 Screw 3/8-16 x .75
5 532 15 52-72 Bumper Hood/Dash
6 532 18 44-19 Saddle
8 532 12 64-71 Clip Insulator 13/32 Mtg. Hole
9 532 18 54-80 Dash
10 872 14 06-08 Bolt, Carriage 3/8-16 x 3/4
11 532 17 49-96 Panel, Dash, L.H.
12 532 14 56-60 Clip Tinnerman Grille P/L
13 532 18 17-19 Panel, Asm. Dash R.H.
15 874 18 05-12 Screw, Machine, Truss Head
5/16-18 UNC x 3/4
16 873 51 05-00 Nut
17 532 16 35-57 Hood Assembly
18 532 18 49-21 Bumper Hood
24 874 78 06-16 Bolt
25 819 13 13-12 Washer 13/32 x 13/16 x 12 Gauge
26 873 80 06-00 Nut
28 532 17 91-01 Grille Lens Asm
29 532 16 81-54 Lens
30 532 18 13-59 Fender
31 532 16 51-56 Bracket, Fender Support
33 532 18 11-93 Footrest, L.H.
34 532 18 11-94 Footrest, R.H.
35 872 11 06-06 Bolt
37 817 49 05-08 Screw Thdrol 5/16-18 x 1/2 TYT
38 532 18 17-48 Bracket Asm Pivot Mower Rear
51 873 80 04-00 Nut Lock w/Insert 1/4-20 UNC
52 819 09 14-16 Washer 9/32 x 7/8 x 16 Ga.
53 532 14 46-97 Bracket Grille Lh
54 532 16 14-64 Screw Hex Wshd 8-18 x 7/8
55 532 14 46-96 Bracket Grille Rh
57 874 78 04-12 Bolt, Fin Hex 1/4-20 UNC x .75
58 532 15 01-27 Duct Air Engine Pl/Lt
69 532 14 24-32 Screw Hex 1/4-1/2
89 532 18 13-88 Console
145 532 15 65-24 Rod Pivot Chassis/Hood
162 532 18 03-84 Bracket Exten Chassis Lh CRD
163 532 18 03-83 Bracket Exten Chassis Rh CRD
164 532 16 56-05 Support Battery CRD
165 532 18 13-56 Cover Battery CRD Lt
170 532 17 88-62 Backplate CRD
171 872 14 06-20 Bolt Rdhd Sqnk 3/8-16 x 2-1/2 G5
172 819 13 20-16 Washer 13/32 x 1-1/4 x 16 Ga.
173 873 51 06-00 Nut, Keps Hex 3/8-16 UNC
175 532 18 03-10 Trap Door CRD
179 532 18 03-76 Rod Pivot FBI CRD
184 532 17 46-62 Bracket Actuator Bagger CRD
185 532 18 11-01 Knob Rod
186 532 16 07-93 Latch Asm Multch Bagger
187 532 12 50-04 Nut Weld .327/.304 #10-24
188 819 06 12-16 Washer #10
189 810 07 10-00 Washer Lock #10
190 871 08 10-10 Screw Pan Hd Phillips 10-24 x 5/8
198 532 16 89-37 Nut Push
205 817 49 06-08 Screw 3/8-16 x 1/2
207 817 06 05-08 Screw 5/16-18 x 1/2
208 817 67 06-08 Screw Thdrol 3/8-16 x 1/2
209 817 00 06-12 Screw Hex Wsh Thdrol 3/8-16 x 3/4
212 532 15 62-29 Insert Lens Refl ective
214 532 12 47-88 Retainer Spring 1"
256 532 18 13-61 Cover Fender Rack CRD
265 532 18 57-04 Seal RH Side Bagger
266 532 18 57-03 Seal LH Side Bagger
- - 532 00 54-79 Plug, Button
