HURTLE ScootKid - Seat Disassembly - Method 1; Folding Seat Housing; Seat Disassembly - Method 2; Handlebar and Seat Component Removal

www.PyleUSA.com
11
SEAT DISASSEMBLY - FIRST METHOD
WARNING: Keep the kids in a safe distance while disassembling the scooter to avoid accidental injuries.
SEAT DISASSEMBLY - SECOND METHOD
A
Scooter as shown in Figure A.
B
Fold the seat housing up as shown
in Figure B.
C
Loose the screw,
press red button
and remove the
sleeve and seat
housing.
A
Scooter as shown
in Figure A.
Press the red button,
remove the handlebar
from the hole on the
scooter
Press the red button, insert the
sleeve and handlebar into the
scooter
E
Scooter as shown in Figure E.
D
B
