Parts List - Motor/Pump Assembly
ITEM NUMBER PART NUMBER QUANTITY DESCRIPTION
1 NA 3 SCREW, M4 X 8
2 NA 3 LOCK WASHER, M4
3 042-0112 1 INLET COVER
4 118-0032 2 SCREEN
5 019-0220 1 FILTER, FELT
6 NA 4 SCREW, M8 X 60
7 NA 16 LOCK WASHER, M8
8 042-0108 1 HEAD ASSEMBLY
9 NA 4 SCREW, M8 X 35
10 046-0283 1 GASKET, HEAD
11 043-0180 1 VALVE PLATE ASSY
(includes items 10 & 12)
12 046-0282 1 GASKET,CYLINDER
13 NA 12 SCREW, M8 X 20
14 050-0061 1 CYLINDER
15 046-0281 1 GASKET, CRANKCASE
16 049-0048 1 CRANKCASE
(includes item 22)
17 056-0074 1 BREATHER
18 077-0185 1 CAP
19 NA 6 SCREW, M6 X 20
20 NA 6 LOCK WASHER, M6
21 046-0280 1 GASKET
22 051-0099 1 BEARING 205
23 NA 1 OIL DRAIN PLUG, 3/8˝ NPT
24 032-0072 1 OIL SIGHT GLASS W/ O-RING
25 053-0100 1 CRANKSHAFT
26 051-0100 1 BEARING 206
27 046-0284 1 GASKET
28 077-0172 1 CARRIER
29 046-0285 1 OIL SEAL
30 044-0064 1 FLYWHEEL, 12˝ A GROOVE
31 146-0026 1 KEY, 5MM X 5MM
32 NA 1 FLYWHEEL WASHER
33 NA 1 SCREW, M8 X 25
34 051-0098 2 PAIR INSERT BEARING
35 047-0086 2 ROD
36 048-0116 2 PISTON ASSEMBLY
37 054-0235 2 RING SET
NA: These are standard parts available at your local hardware store.
