4
Max
Torque
(ft-lb)
Free
Speed
(RPM)
Weight
(lbs)
Length
(in)
Air Cons.
(CFM)
Always use clean dry air. Excessive moisture and dirt will greatly reduce the life of any air motor. We recommend the installation
of an in-line filter-regulator-lubricator as close to the tool as possible. A 3/8" air hose is required up to a length of 8 ft. If more
length is required a 1/2" air hose should be connected to the 3/8" hose to ensure the tool has the necessary air supply. Be sure
all hoses and fittings are the correct size and tightly secured. Before the tool is connected to the air supply, clear the air hose of
accumulated dust and moisture. Before removing a tool for service or changing sockets, make sure the air line is shut-off and
drained of air. This will prevent the tool from operating if the throttle s accidentally engaged.
