5
Assembly
Care and Cleaning
WARNING: Always make sure that the worklight is detached
and cooled down before attempting to clean it.
Clean the tripod regularly with a non-abrasive cleaner.
Store in a safe and dry place, out of the reach of children.
Installation mode-2
Latch (B4)
open latch (B4), then put the post (2) of the light into the center
of the mount (A). Then close the latch (B4) to secure the light.
To remove the light from the mount (A), open the latch (B4) and
lift the light.
Push screw knob (1) up, insert the screw into the threads at the
bottom of the light, then twist and tighten the screw knob (1) .
To remove the light from the mount (A), unscrew knob (1) and lift
the light.
Installation mode-3
Mount (A)
Mount (A)
Screw knob (1)
Post (2)
