Husqvarna YTH2246TDR Illustrated Parts List

5
KEY PART
NO. NO. DESCRIPTION
1 532 16 34-65 Battery
2 874 76 04-12 Bolt Hex Head 1/4-20 x 3/4
8 532 18 64-91 Box Battery
16 532 17 61-38 Switch Interlock Push-In
21 532 40 02-52 Harness Socket Light w/4152J
22 532 00 41-52 Bulb Light
24 532 40 02-53 Cable Battery
25 532 41 28-95 Cable Starter
26 532 17 51-58 Fuse
27 873 51 04-00 Nut Keps Hex 1/4-20 unc
28 532 14 54-91 Cable, Ground
29 532 40 15-45 Switch, Seat
30 532 19 33-50 Switch, Ign
33 532 41 19-33 Key\Chain
34 532 11 07-12 Switch Light / Reset
40 581 02 28-01 Harness Ign. Dash
41 817 72 04-08 Screw Thd Cut 1/4-20 x 1/2
42 532 13 15-63 Cover, Terminal
43 532 19 25-07 Solenoid
46 532 40 17-63 Gauge Servicereminder Hrmtr
50 532 17 46-51 Switch PTO
55 817 06 05-12 Screw Thdrol 5/16-18 x 3/4 TYTT
59 532 40 03-03 Outlet 12-Volt
71 532 19 42-76 Harness Ign. Chassis
79 532 17 52-42 Socket Asm Bulb Twistlock
81 532 40 96-15 Relay Harness Sealed
90 532 43 53-95 Cover Terminal
91 532 19 02-70 Strap Battery Mount
99 817 67 04-12 Screw Hexwsh Thdrol 1/4-20 x 3/4
100 819 09 14-16 Washer 9/32 x 7/8 x 16 Ga.
102 532 40 44-54 Harness Pigtail
103 532 40 79-62 Harness Pigtail 12-Volt
105 532 40 75-68 Switch Reverse TT Pedal Control
142 583 85 78-01 Charge Port Pigtail
143 532 44 80-59 Indicator Battery
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
TRACTOR - - MODEL NO. YTH2246TDR (96041027201/02), PRODUCT NO. 960 41 02-72
ELECTRICAL
32
32
