Husqvarna YTH2246TDR Illustrated Parts List

7
KEY PART
NO. NO. DESCRIPTION
3 532 43 97-52 Applique
5 532 43 74-86 Dash
14 532 44 11-77 Hood
15 532 43 97-33 Lens LH
18 532 43 77-62 Grille
25 532 44 33-85 Lens RH
34 580 91 08-01 Plate Engine
36 817 06 05-12 Screw 5/16-18 x 3/4
37 532 44 12-08 Fender
52 873 68 05-00 Nut Lock 5/16-18
58 532 41 22-81 Drawbar Upper
68 817 49 05-08 Screw Thdrol 5/16-18 x 1/2
125 581 68 48-01 Clip Fuel Line
130 532 41 63-58 Screw 10 x .750 BOS Thread
137 532 40 75-90 Bumper Dash
146 581 85 79-01 Bolt
150 532 43 97-74 Air Duct
151 532 43 66-70 Bracket Pivot Hood
152 532 43-98-70 Shield Browning
159 817 00 06-12 Screw Hexwsh Thdr 3/8-16 x 3/4
161 532 43 99-29 Window, Fuel
162 532 14 24-32 Screw Hex Wsh 1/4 x 1/2 unc
165 532 19 68-26 Support Tank Rear
175 532 19 63-04 Crossmember
176 532 40 07-76 Screw 10-24 x 5/8
177 532 19 52-27 Bushing Steering
178 532 19 97-82 Cargo Net Asm.
180 532 41 50-64 Chassis
182 532 40 68-59 Dash Lower
183 874 52 05-20 Bolt 5/16-18 x 1-1/4 Full Thd.
189 817 00 05-12 Screw 5/16-18 x 3/4
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
KEY PART
NO. NO. DESCRIPTION
191 532 43 74-55 Insert Reflective LH
194 873 90 05-00 Nut Lock Hex Flange 5/16-18
196 532 43 96-74 Console Asm Decklift
199 532 19 82-59 Plate Deck Lift
202 532 43 97-28 Vent Side Hood RH
203 532 43 97-27 Vent Side Hood LH
204 532 43 57-14 Vent Top Hood
205 532 43 97-30 Skirt Hood Side RH
206 532 43 97-29 Skirt Hood Side LH
207 532 43 97-34 Bezel RH
208 532 43 97-35 Bezel LH
213 874 76 05-12 Bolt 5/16-18 x 3/4
214 532 19 91-45 Clip Retainer Tinner
217 532 40 91-67 Rod Pivot
218 532 19 63-95 X-Piece Hood Stop
221 532 19 89-09 Reflective LH
228 532 19 51-61 Stud Fastner
234 532 40 47-42 Bumper Hood
235 532 40 61-29 Spacer Fender
236 873 93 05-00 Nut Lock 5/16-18 unc
297 532 43 74-56 Insert Reflective RH
306 873 90 06-00 Nut Lock
335 532 44 82-04 Cover RH Close Out
336 532 44 53-09 Cover LH Close Out
350 532 44 51-43 Clip X-mas Tree
- - 532 43 18-83 Kit Bumper
TRACTOR - - MODEL NO. YTH2246TDR (96041027201/02), PRODUCT NO. 960 41 02-72
CHASSIS AND ENCLOSURES
