HACCP
Actual temperature measurement for the HACCP
h01
Last registered peak temperature
h10
Selection of function and sensor for the HACCP
HACCPfunction.1=S4used(maybealsoS3).2=S5
h11 0 2 0 0
Alarm limit for the HACCP function
h12 -50.0°C 50.0°C 8.0°C 8.0°C
Time delay for the HACCP alarm
h13
0 min. 240 min. 30 min. 30 min.
Select signal for the HACCP function. S4% (100% = S4,
h14 0% 100% 100% 100%
Real time clock
Six start times for defrost.
Setting of hours.
0=OFF
t01-t06
0 hours 23 hours 0 hours 0hours
Six start times for defrost.
Setting of minutes.
0=OFF
t11-t16
0 min 59 min 0 min 0min
Clock - Setting of hours
t07
0 hours 23 hours 0 hours 0hours
Clock - Setting of minute
t08
0 min 59 min 0 min 0min
Clock - Setting of date
t45 1 31 1 1
Clock - Setting of month
t46 1 12 1 1
Clock - Setting of year
t47 0 99 0 0
Miscellaneous
Delay of output signals after start-up
o01
0 s 600 s 5 s 5s
input signal on Di1. Function4
o02 1 11 0 0
Network address
o03 0 240 0 0
On/Off switch (Service Pin message)
o04 OFF ON OFF OFF
Access code 1 (all settings)
o05 0 100 0 0
9sed sensor type (Pt /PTC/NTC)
o06 Pt ntc Pt Pt
Display step = 0.5 (normal 0.1 at Pt sensor)
o15 no yes no no
Maxholdtimeaftercoordinateddefrost
o16
0min 60min
20 20
Select signal for display view. S4% (100%=S4, 0%=S3)
o17 0% 100% 100% 100%
input signal on Di2. Function4
o37 0 12 0 0
Configuration of light function (relay 4)
o38 1 3 1 1
Activation of light relay (only if o38=2)
o39 OFF ON OFF OFF
Rail heat On time during day operations
o41 0% 100% 10 0 100
Rail heat On time during night operations
o42 0% 100% 10 0 100
Rail heat period time (On time < Off time)
o43
6 min 60 min 10 min 10 min
Case cleaning. 0=no case cleaning. 1=Fans only. 2=All
o46 0 2 0 0
Selection of EL diagram. See overview page 6
o61 1 10 1 1
Download a set of predetermined settings. See
o62 0 6 0 0
Access code 2 (partly access)
o64 0 100 0 0
Save the controllers present settings to th e
o65 0 25 0 0
Load a set of settings from the programming key
o66 0 25 0 0
Replace the controllers factory settings with th e
o67 OFF On OFF OFF
Service
Statuscodesareshownonpage17
S0-S3 3
Temperature measured with S5 sensor
u09
Status on Di1 input. on/1=closed
u10
Temperature measured with S3 sensor
u12
Status on night operation (on or off ) 1=closed
u13
Temperature measured with S4 sensor
u16
Thermostat temperature
u17
Read the present regulation reference
u28
Status on Di2 output. on/1=closed
u37
Temperature shown on display
u56
Measured temperature for alarm thermostat
u57
Status on relay for cooling
u58
Status on relay for fan
u59
Status on relay for defrost
u60
Status on relay for railheat
u61
Status on relay for alarm
u62
Status on relay for light
u63
Status on relay for valve in suction line
u64
Status on relay for compressor 2
u67
Controller Parameters (Cont'd)
25
