Hussmann Corporation • Bridgeton, Missouri 63044-2483 U.S.A.
Innovator Door Installation and Service Instruction
P/N 0425683_M
19
WIRING COLOR CODE
Leads for all electrical circuits are identied by a colored plastic
band: neutral wire for each circuit has either White insulation or a
White plastic sleeve in addition to the color band.
Pink............ RefRig. TheRmosTaT Low TemP. oRange oR
LighT BLue . RefRig. TheRmosTaT noRm TemP. Tan .........LighTs
DaRk BLue . DefRosT TeRm. TheRmosTaT maRoon ..RecePTacLes
PuRPLe ....... conDensaTe heaTeRs YeLLow ...DefRosT heaTeRs 120V
BRown ....... fan moToRs ReD ........DefRosT heaTeRs 208V
gReen* ....... gRounD *eiTheR coLoReD sLeeVe oR coLoReD insuLaTion
ELECTRICIAN NOTE: Use copper conductor wire only.
CASE MUST BE GROUNDED
These aRe maRkeR coLoRs wiRes maY VaRY.
EcoShine II — LED Light Specifications
Neutral White
Warm Neutral
Cool White
Energy Energy Efficacy
Watts Watts CRI (Lumens/
Hussmann (DC) (AC) Rating Length Watts)
Part Number Description Per Fixture Per Door (typical) (inches) Nominal
0530523 EcoShine II Reach-In / Walk-In 3500K 48 in. 6.6 7.7 85 48.5 65
0530526 EcoShine II Reach-In / Walk-In 3500K 56 in. 7.7 9.0 85 55.1 65
0530529 EcoShine II Reach-In / Walk-In 3500K 62 in. 8.2 9.5 85 59.5 65
0530532 EcoShine II Reach-In / Walk-In 3500K 68 in. 9.4 10.9 85 66.1 65
0530538 EcoShine II Reach-In / Walk-In 3500K 72 in. 10.0 11.6 85 70.4 65
0530535 *EcoShine II Reach-In / Walk-In CS 3500K 68 in. 9.4 10.9 85 66.1 65
0530541 *EcoShine II Reach-In / Walk-In CS 3500K 72 in. 10.0 11.6 85 70.4 65
0530524 EcoShine II Reach-In / Walk-In 4000K 48 in. 6.6 7.7 85 48.5 65
0530527 EcoShine II Reach-In / Walk-In 4000K 56 in. 7.7 9.0 85 55.1 65
0530530 EcoShine II Reach-In / Walk-In 4000K 62 in. 8.2 9.5 85 59.5 65
0530533 EcoShine II Reach-In / Walk-In 4000K 68 in. 9.4 10.9 85 66.1 65
0530539 EcoShine II Reach-In / Walk-In 4000K 72 in. 10.0 11.6 85 70.4 65
0530536 *EcoShine II Reach-In / Walk-In CS 4000K 68 in. 9.4 10.9 85 66.1 65
0530542 *EcoShine II Reach-In / Walk-In CS 4000K 72 in. 10.0 11.6 85 70.4 65
0530525 EcoShine II Reach-In / Walk-In 5000K 48 in. 6.6 7.7 85 48.5 65
0530528 EcoShine II Reach-In / Walk-In 5000K 56 in. 7.7 9.0 85 55.1 65
0530531 EcoShine II Reach-In / Walk-In 5000K 62 in. 8.2 9.5 85 59.5 65
0530534 EcoShine II Reach-In / Walk-In 5000K 68 in. 9.4 10.9 85 66.1 65
0530540 EcoShine II Reach-In / Walk-In 5000K 72 in. 10.0 11.6 85 70.4 65
0530537 *EcoShine II Reach-In / Walk-In CS 5000K 68 in. 9.4 10.9 85 66.1 65
0530541 *EcoShine II Reach-In / Walk-In CS 5000K 72 in. 10.0 11.6 85 70.4 65
* For walk-in close spacing placement. The light source for close spaced walk-in lights is visible.
EcoShine II and EcoShine II Plus LED lights are covered by a 5 year limited parts and labor warranty.
See Hussmann warranty policy for additional details.
Color Temperature:
Color temperature is measured in kelvins (K). Higher color temperatures produce bright, white light hues. Cool White
(5000K) has the brightest white hue. Neutral White (4000K) has a cooler hue than Warm Neutral (3500K).
