HUST CNC H6D-T Manual
IV
4.2 Description of Parameters 4-5
5 Connections 5-1
5.1 System Connection Descriptions 5-1
5.2 System Installation 5-2
5.2.1 Operating Environment 5-2
5.2.2 Considerations for the design of control panel 5-2
5.2.3 Internal temperature design 5-2
5.3 H6D-T External Dimensions 5-4
5.3.1 H6D-T Controller 5-4
5.3.2 H6DL-T Controller 5-6
5.3.3 H6D-T Auxiliary Panel 5-8
5.3.4 H6DL-T Auxiliary Panel 5-9
5.3.5 H6D-T Accessories Dimensions 5-10
5.4 Connector Type 5-12
5.5 Connector Name 5-12
5.6 Connector Pin-out Definition 5-13
Axis Connector Pin 5-13
MPG (H6D) 5-14
MPG (H9D) 5-15
AD/DA Analog Signal Wiring 5-16
5.6.1 G31 INPUT Control Signals 5-17
5.6.2 Axial Control, pin assignment and wiring 5-18
5.6.3 Wiring of Manual Pulse Generator (MPG) 5-19
5.6.4 Wiring of Spindle Control 5-20
5.6.5 I/O Wiring 5-22
5.6.6 I/O Wiring Schematic 5-24
5.6.7 Wiring of System AC Power Supply 5-30
5.6.8 Servo on Wiring Examples 5-31
6 Error Messages 6-1
7 Appendix A 7-1
