HUSTLER 3500 Owner's Manual

109627_0910 3-5
variable from zero to full rated speed in each range.
The ground speed is controlled by these pedals.
Depress the forward travel pedal to progressively
increase forward speed. For reverse travel, depress the
reverse travel pedal. NOTE: These pedals must be in
neutral (not depressed) to start the engine.
F. Cruise control switch (Figure 3-8) — Used to
maintain a constant forward speed. After attaining the
desired speed with the forward travel pedal, put the
switch to the “ON “position, and the unit will maintain
the set speed when the pedal is released.
To cancel the speed setting or stop the unit, put the
cruise control switch to the “OFF” position or firmly
depress the master brake pedal.
WARNING: To avoid injury, the cruise control
switch should not be put in the “ON” position
when operating at transport speed or when in
reverse.
G. Transmission Selector lever (Figure 3-9 & Figure 3-
10) — The Range Selection and the All Wheel Drive
(AWD) Selection are controlled by the Transmission
Selector lever. This lever can only be shifted when the
HST foot pedal is in the Neutral position
When the Transmission Selector lever is located in the
inside slot, the tractor will run in Automatic AWD
mode. When the lever is in this position there are
three settings: High range (H), Low range (L) and
Neutral.
Figure 3-6
Figure 3-7
Park brake lever
Release button
C
Differential lock pedal
D
Figure 3-8
Figure 3-9
Figure 3-10
F
Transmission selector lever shown
in the Automatic AWD position
G
Transmission selector lever shown
in the locked AWD position
High range
Low range
G
