C (5
o
)
D (10
o
)
E (15
o
)
Line A
Line B
Slope Guide Lines
F (25
o
) - Hustler ATZ only
601656_1108
1. Hold this sheet of paper in front of you. Make sure that line A is horizontal.
2. Align line B with a vertical surface such as a pole, tree or building.
3. Fold the paper along the slope guide lines (C, D or E).
4. Align the closest slope guide line with the ground slope. This will give you a close estimation of the ground slope to be
mowed.
SLOPE GUIDE
Figure 2-1
Use this diagram when determining the degree of slope to be mowed.
