110907 01/09 4-5
Fuel System Installation
NOTES:
1. Torque to 7 ft-lbs.
2. Service parts for fuel tanks (not shown):
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY DESCRIPTION
1 779306 779306 1 3.5" FUEL CAP
2 110080 110080 1 FENDER RH
3 110081 110081 1 FENDER TANK LH
4 785295 N/A 1 GROMMET, FUEL SHUTOFF VALVE
5 601805 N/A 1 SUCTION HOSE ASSY 22.0
6 768523 768523 8 FW .343X.687X.051/.080H
7 034280 034280 6 CS .312-18X .750 HX G5
8 000323 000323 2 CLIP
9 015818 015818 1 FUEL LINE, 9"
10 015818 015818 1 FUEL LINE, 12"
SERVICE PART NO. DESCRIPTION
785295 FLANGE GROMMET
601805 SUCTION HOSE ASSY 22.0
