HUSTLER 929125 - Access to Hydro-Gear EZT Transmissions; Hydraulic System

9-14 110907 01/09
Access to Hydro-Gear EZT transmissions
The integrated pump/motor units are accessed by lifting the seat platform. The seat platform is hinged at the front.
To raise it, remove the lock nut and tilt seat platform up and forward.
If the seat is equipped with the optional arm rest kit, make certain to place the control arms in the park brake
position and pivot the arm rests upward before placing the seat platform in the full forward position to prevent
damage to the arm rests.
Hydraulic system
The HustlerSport is equipped with two Hydro-Gear EZT integrated pump/motor transmissions (FIG. 18).
The EZT integrated pump/motor transmission are sealed for life and do not require any scheduled service.
The EZT integrated pump/motor transmissions are filled with 20W50 engine oil. If they ever become low on oil fill to
the level shown inFIG. 19..
FIG. 18
FIG. 19
EZT
EZT
