110907 01/09 5-3
Front Wheel Assembly
NOTES:
1. Apply grease to zerks (see owners manual).
2. Tighten, then back off until wheel spins freely.
3. Assemble with extended inner race down. Apply a thin continuous bead
of Loctite® 609 to O.D. of outer races of bearings prior to assembling
bearing into frame.
4. Apply Loctite® 242 to threads.
5. Appy Anti-Sieze to caster pivot shaft.
ITEM NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY DESCRIPTION
1 705954 705954 2 CS .500-13 X 1.25 HX G5 ZN
2 344267 344267 2 FW .510 X 2.15 X .187 SPL ZN
3 712976 712976 2 FW .531X 1.375X.125 ZNY
4 784223 784223 4 BEARING W/O COLLAR
5 784603 784603 2 SPACER
6 339689 339689 2 CASTER FORK
7 042630 042630 2 CS .500-13X6.50 HX G5 Z
8 767962 767962 4 FW .531X 1.063X.090 SAE
9 781567 781567 2 NT .500-13 HX G8 ZY NL
10 768044 768044 2 TIRE/WHL 11X4-5 RIBBED
11 306969 306969 2 GAGE WHEEL SPACER
