48" Side Discharge Deck Pulley Assembly
NOTES:
1. Torque to 73 ft. lbs.
2. Torque to 145 ft-lbs.
3. See “48" Deck Belt Routing and Tensioning” on page 7-6 for belt
tensioning.
4. See “Spindle Assembly–601804” on page 6-10 for breakdown.
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY DESCRIPTION
1 771634 771634 1 B-SECTION BELT
2 794446 794446 3 CS .625-11X1.500 HX G5
3 046821 046821 3 FW .656X 2.00X.078 ZNYC
4 797449 797449 4 FW .650X1.125X.18 ZNYCG5
5 784504 784504 3 PULLEY, IDLER, 5.00"OD
6 109770 109770 1 IDLER SLIDE W/A
7 781302 781302 1 IDLER SPRING
8 259812 059931 1 CHAIN DECK LIFT SPRING (13 LINKS)
9 784199 784199 4 CS .312-18X1.250 FLT SH
10 601619 601619 2 IDLER SLIDE UHMW RT & LT
11 034280 034280 2 CS .312-18X .750 HX G5
12 768523 768523 6 FW .343X.687X.051/.080H
13 110840 110840 1 PULLEY COVER, LH
14 110841 110841 1 PULLEY COVER, RH
15 705954 705954 3 CS .500-13X1.25 HX G5 Z
16 798603 798603 3 FW .515X1.65X.125 HD ZY
17 792689 792689 3 PULLEY 5.00"OD
18 054502 054502 12 NT .375-16 HX GRD 5 ZNY
19 767954 767954 24 FW .406X .812 X.060 SAE
20 058776 058776 4 NT .312-18 HXZY NL
21 601804 601804 3 SPINDLE ASSEMBLY
22 005116 005116 12 CS .375-16X1.375 HX G5
23 601123 601123 3 BLADE, 16.50"-L-F-CW
24 782474 782474 3 CW .631 2.250X .187 PNT
25 781872 781872 3 CS .625-11X1.25 HX G5 Z
