42" Side Discharge Deck Assembly
NOTES:
1. Do not torque, Item 2 (601117 Discharge Chute) must pivot freely.
2. Includes items 10, 11, 12, and 13.
3. Service part deck includes decals (see “42" Side Discharge Deck
Decals” on page 8-5 for listing of decals).
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY DESCRIPTION
1 550011 110150 1 42" DECK WA
2 601117 601117 1 RUBBER CHUTE ASSEMBLY
3 086660 086660 6 NT .375-16 HXZY NL
4 767954 767954 8 FW .406 X .812 .060 SAE HD ZN
5 036244 036244 2 CS .375-16X1.000 HX G5
6 357103 357103 1 DISCHARGE CHUTE BRACKET W/A
7 110912 110912 1 DISCHARGE SPORT ADAPTER
8 025395 025395 4 CB .375-16 X 1.00 STD CD
9 601069 601069 4 CN .312-18X.200 MAX THK
10 781708 N/A 1 CS .500-13 X 4.25 HX G5 ZN
11 767962 N/A 2 FW .531 X 1.063 X .090 SAE HD ZN
12 031997 N/A 1 ANTI-SCALP WHEEL
13 053199 N/A 1 NT .500-13 HX JAM ZN
14 781567 781567 1 NT .50-13 HX LK NY
788166 788166 1 ANTI SCALP WHEEL ASSY
