HUSTLER Diesel Z User Manual

603695 4-13 REV F
Hustler Diesel Z Maintenance Locator Chart
Figure 4-23
Figure 4-24
1. Engine Oil Dipstick
2. Fuel Filter
3. Engine Air Cleaner
4. Engine Oil Drain Plug
5. Battery
6. Fuel Tanks
7. Hydraulic Oil Reservoir
8. Hydraulic Oil Filter
9. Gauge Wheel Bearing Zerks (2)
10. Engine Oil Filter
11. Deck Height Pivot Zerks (4)
12. Park Brake Switch
13. Drive Tire
14. Pump Idler Zerk (1)
15. Pump Belt
16. Deck Drive Belt
17. Engine Coolant Fill
18. Engine Oil Fill
19. Hydraulic Oil Heat Exchanger
Figure 4-25
Figure 4-26
1
3
5
6
6
11
19
9
12
9
11
12
11
7
11
17
18
2
1
16
14
10
15
13
13
4
8
16
