602901 3-9 REV G
steering control lever and finish the turn. (Figure 3-9)
IMPORTANT: Rapid movement of steering control levers
is not recommended as damage to the hydraulic system compo
-
nents may occur.
To increase speed, increase steering control lever’s distance
from neutral. The farther forward steering control levers are
from neutral, the faster the mower will travel forward. The
farther back steering control levers are from neutral, the faster
the mower will go in reverse.
Always be aware of what is behind the machine before
backing up. Do not mow in reverse unless absolutely nec
-
essary. Always look down and behind before and while
backing up.
Figure 3-8
FORWARD TRAVEL
FRONT OF MOWER FACES THIS DIRECTION
ZERO RADIUS TURN
FORWARD TRAVEL
RIGHT TURN
REVERSE TRAVEL
RIGHT TURN
REVERSE TRAVEL
N = NEUTRAL POSITION
Direction of arrows indicate direction of mower
movement
N
N
N
N
N
N
N
N
N
N
