607768 2-7 REV A
Part Number 785139 & 785220
785220C E
785139C E
Park brake position Park brake positionForward position
Reverse position
DANGER: Battery Hazards!
Part Number 601815
601815
• Do not overfill battery.
• Electrolyte may overflow and damage
paint, wiring or structure. When cleaning
the battery, use soap and water. Be
careful not to get soap and water into the
battery. Use soda mixed in water to
clean corrosion off the terminals.
• Always wear eye protection when
checking the battery, acid can cause
serious injury to skin and eyes. If contact
occurs, flush area with clean water and
call physician immediately. Acid will also
damage clothing.
• Avoid skin contact
with battery acid
• Do not allow open flame near the
battery when charging.
• Hydrogen gas forms inside the
battery. This gas is both toxic and
flammable and may cause an
explosion if exposed to flame.
Always remove the negative ground
first and replace it last.
WARNING: Fire!
Part Number 601967
• Clean flammable material from
machine. Prevent fires by keeping
engine compartment, top of deck,
exhaust area, battery, fuel line, fuel
tank and operator’s station clean of
accumulated trash, grass clippings,
and other debris. Always clean up
spilled fuel and oil.
601967
Top of Deck Clutch Switch Shown
A. Deck clutch disengaged (OFF) position
B. Deck clutch engaged (ON) position
A
B
To Next Page
