Comments for Page: Engine, Kohler CV730 & CV740
1. Supplied with the engine.
2. Part of the wire harness.
3. Torque to 30 ft-lbs.
Item Part No. Qty Name
1 1 KOHLER CV730 ENGINE
Not Shown 1 KOHLER CV740 ENGINE
2 788943 1 AIR FILTER INDICATOR
3 601216 1 FTG, ELBOW, STREET
4 796672 1 VALVE,OIL DRAIN 3/8-18
5 787713 3” HOSE, 1/2" LOW PRESSURE
6 058776 2 NT .312-18NLG5
7 768523 5 FW 0.343SAE
8 602776 1 MUFFLER, CV750
9 029751 2 CS .375-16X1.00 HXF G5ZN
10 705137 4 FW 0.391X1.25X.06 ZN
11 786632 1 BATTERY CABLE, POS RED
12 744284 1 BATTERY CABLE NEGATIVE
13 111894 1 GROUND STRAP W/A
14 789131 1 CAP, HUSTLRZ FAN CON(FS)
15 000331 4 WIRE TIE, SMALL/SHORT
16 603112 2 CLAMP, 3/16 FUEL
17 603326 36" VAPOR LINE, 3/16"
Comments for Part Num. 603326
Sold by the foot.
18 000323 2 CLIP, HOSE CLAMP
19 015818 29" FUEL LINE, 1/4"
Comments for Part Num. 015818
Sold by the foot.
20 034280 1 CS .312-18X0.750HXG5
21 043570 1 CLIP - HOSE - SINGLE(FS)
22 034272 2 NT .312-18HXG5
23 016899 2 NT .375-16 FLKG5
24 792788 4 SC0.375-16X1.000FLG
Engine, Kohler CV730 & CV740 Hustler X-ONE Parts Manual
Tue May 19 17:15:13 UTC 2020 6.3-1
