HUSTLER X-ONE 930511 - 54 Rear Discharge - Deck Belt, Pulley Covers & Blades

Comments for Page: 54" Rear Discharge - Deck Belt, Pulley Covers & Blades
1. Torque to 118 ft-lbs.
2. 604383 and 781872 are used on mowers S/N 12092657 & higher.
3. 601999 and 601983 are used on mowers S/N prior to 12092657.
4. 550914 includes decals.
Item Part No. Qty Name
1 550914 1 SVC PULLEY COVER RS CE
2 110448 1 PULLEY COVER, LH
3 601837 1 DECAL, DECK DANGERS
4 792002 4 KNOB,5/16-18 X 3/4"MALE
5 601015 1 DECK BELT
6 781567 1 NT .500-13NLG5
7 767962 1 FW .531 x 1.063 x .175
8 602341 1 WHEEL, ANTI-SCALP
9 602344 1 SPACER, ANTI- SCALP 5.73
10 602338 1 CB .50-13 X 7.50 STD ZN
11 601013 1 BLADE, F18.50-L-F-CCW
12 782474 3 CW .678 X 2.250 X .187
13 604383 1 CS .625-11X1.250 G5 LHT
Not Shown 601999 1 CS .625-11 X 2.25 LH H5
14 114013 1 BAFFLE, ADJUSTABLE RS
15 114014 1 BAFFLE, ADJUSTABLE LS
16 055822 6 CS .375-16X0.75 HX G5 ZN
17 767954 6 FW 0.379X.82X.06 HD ZN
18 601012 2 BLADE F18.50"-L-F-CW
Not Shown 601124 2 BLADE, 18.50"-L-F-CW
19 781872 2 CS .625-11X1.250HXG5
Not Shown 601983 2 CS .625-11 X 2.25 HXG5ZN
54" Rear Discharge - Deck Belt, Pulley Covers & Blades
Hustler X-ONE Parts Manual
Tue May 19 17:15:44 UTC 2020 8.3-5
