Item Part No. Qty Name
1 603807 2 CAP, 3.5" RATCHETING GAS
2 604524 1 S/C TO 605107
3 604525 1 S/C TO 605108
4 000323 4 CLIP, HOSE CLAMP
5 015818 59" FUEL LINE, 1/4"
Comments for Part Num. 015818
Sold by the foot.
6 745059 1 FUEL VALVE 3-WAY
7 712919 10 FW 0.406X1.00X.12 HD ZN
8 055822 10 CS .375-16X0.75 HX G5 ZN
9 034280 7 CS .312-18X0.750HXG5
10 768523 14 FW 0.343SAE
11 043570 3 CLIP - HOSE - SINGLE(FS)
12 034272 7 NT .312-18HXG5
13 055947 4 CS .250-20X0.50 HX G5 ZN
14 768515 4 FW 0.281SAE
15 116229 1 COVER, REAR
16 116228 1 COVER, FRONT
17 604281 1 TEE, 3/16" PLASTIC
18 604314 2 CARBON CANISTER, 9 GAL
19 602980 4 CLAMP, CUSHIONED 3.0"
20 603326 89" VAPOR LINE, 3/16"
Comments for Part Num. 603326
Sold by the foot.
Fuel System with Carbon Canister–S/N 13020001 & HIGHER (Multi-Page)
Hustler X-ONE Parts Manual
Tue May 19 17:15:08 UTC 2020 6.2-7
