Product Description
DOCUMENT HQI-J-FC1-001
ES_DATE 2019-07-19
Fundus camera
HFC-1
RE_DATE 2020-06-08
REV R-3 PAGE 22 / 36
Q-I-300-02(R1):2018/06/04 Huvitz Co.,Ltd
7 Hole Mirror
To reflect the Color LED beam
and IR LED beam to the
patient’s eye
2_HOCT-HOLE-MIRROR 8010MIR0012-A
8 W.D LED
To check Working distance
(Objective lens – Patient’s eye
distance)
W2_OT-WD-HOLDER-
ASSY
W2MASSY108-
AA
9
Fundus Diopter
Lens
To take a fundus image of
people with high diopters
W2_OT-DIOPTER-LENS-
ASSY
W2MASSY091-
AA
10
Color Fundus
Camera
The camera for the Color
Fundus image
CAMERA(BFS-U3-
200S6C-C)
72030010002-A
11
IR Fundus
Camera
The camera for the IR Fundus
W2_OT-IRCAMERA-
ASSY
W2MASSY064-
AA
12 IR Fundus Lens
To IR image the Eye to the
observation camera
W2_OT-IR-LENS-ASSY
W2MASSY077-
AA
13
Color Fundus
Lens
To Color image the Eye to the
observation camera
W2_HOCT-I-LENS-1
W2_OT-IM-A-LENS2-
ASSY
8000LEN0100-A
W2MASSY142-
AA
14
Fundus Zoom
Lens
To take fundus image for
multiple diopter eyes
W2_OT-ZOOM12-ASSY
W2MASSY090-
AA
15 Fixation Mirror
To reflect the Fundus beam
and to penetrate the Fixation
LCD beam
W2_HOCT-FIXATION-
MIRROR
8010MIR0017-A
16 Fixation LCD
To illuminate the fixation
target
W2_OT-DOT-LCD-ASSY
W2MASSY057-
AA
17 Fundus Ill. Lens
The lens for illuminate the
Color LED or IR LED to the
eye
W2_OT-ILLUM-LENS1-
ASSY
W2MASSY042-
AA
18
Split Focus
Lens
The lens for illuminate the
Split Focus Illumination to the
eye
W2_OT-SPLIT-LENS-
ASSY
W2MASSY072-
AA
19
Split Focus
Illumination
The illumination for measuring
patient's diopter
W2_OT-SPLIT-LED-ASSY
W2MASSY070-
AA
20 Block Dot
To eliminate the reflected light
from the objective lens
W2_OT-ILLUM-BD-
PLATE-ASSY
W2MASSY044-
AA
21
Fundus Ill. Lens
2
The lens for illuminate the
Color LED or IR LED to the
eye
W2_OT-ILLUM-LENS3-
ASSY
W2MASSY045-
AA
22
Illumination
Mask
The Light Size Transformer for
Small Pupils
W2_OT-ILLUM-MASK2-
ASSY
W2MASSY074-
AA
23 Half Mirror
To reflect the IR LED and to
penetrate the Color LED
W2_HOCT-SOURCE-
MIRROR
8010MIR0018-B
24 Color LED
The illumination for taking
Color Fundus image.
HARNESS(MB(J7) TO
FLASH LED)
W2EHAR0006-
AA
25 IR LED
The illumination for taking IR
Fundus image.
PCB ASSY(NIR LED-100)
W2EPCB0005-
AA
To Next Page
