Product Description
DOCUMENT HQI-J-FC1-001
ES_DATE 2019-07-19
Fundus camera
HFC-1
RE_DATE 2020-06-08
REV R-3 PAGE 34 / 36
Q-I-300-02(R1):2018/06/04 Huvitz Co.,Ltd
modulation
7
Working dot, Focus
Split LED(740nm)
71010040005-
A
L740-36AU,
Marubeni, 1.8V,
50mA, 740nm
15 minutes per 1 patient * 25
patients per 1 day* 260 days
per 1year * 7 years = 11,375
hrs
8
Retina IR
LED(760nm)
71010040008-
A
L760-36AU,
Marubeni, 1.8V,
50mA, 760nm
15 minutes per 1 patient * 25
patients per 1 day* 260 days
per 1year * 7 years = 11,375
hrs
9
Mire Ring, Kerato
Focus LED(940nm)
71010040006-
A
L940D-33,
Marubeni, 1.5V,
100mA, 940nm
15 minutes per 1 patient * 25
patients per 1 day* 260 days
per 1year * 7 years = 11,375
hrs
10
Fundus ,Color
Image Capture
LED(Flash)
W2RTAB-17-
00025
BXRC-50G10K0-L-
24(VERO 29),
BRIDGELUX, 38V,
2.1A, 5000K, 49.2
pi, 10010 lm, 120
degree
20msec per 1 time * 6 times
per 1 patient * 25 patient per
1day * 260day * 7years = 5,460
sec = 1.52 hrs
11 Chinrest Assy
W2MASSY006-
A
KWA-ED2531D1-
002(KWA 0095),
GGM, 12V, 3.6W,
76, KWA 0095
2 times per 1 patient * 25
patients per 1 day* 260 days
per 1year * 7 years = 91,000
times
12 XYZ Moving Assy
W2MASSY014-
A
X,z: Citizen mirco,
RB-35CGM-NCA09-
12D(1/302)
Y: 2.85Vdc, 1.5A
stepping motor
2 times per 1 patient * 25
patients per 1 day* 260 days
per 1year * 7 years
= 91,000 times
