Huvitz HFC-1 - Transportation Environment

Product Description
DOCUMENT HQI-J-FC1-001
ES_DATE 2019-07-19
Fundus camera
HFC-1
RE_DATE 2020-06-08
REV R-3 PAGE 35 / 36
Q-I-300-02(R1):2018/06/04 Huvitz Co.,Ltd
2) Environment: As a result of transportation, HFC-1 meet transportation test condition.
NO Test Name Test condition
Requimrents HAZARD
ID
1
Environmental
condition use
10℃±2, 16H
No malfuction and
performance deterioation.
40℃±2, 16H
No malfuction and
performance deterioation.
40℃±2, RH 95%, 16H
No malfuction and
performance deterioation.
2
Storage
condition :
-10℃±3, 16H
No malfuction and
performance deterioation.
HH-34
55℃±2, 16H
No malfuction and
performance deterioation.
HH-34
55℃±2, RH 95%, 16H
No malfuction and
performance deterioation.
HH-34
3
Transport
condition (slow
temperature
change) :
(-40℃±3) / (70℃±2), 24H,
5Cycle
(1 Cycle = Descent
3H/Keep9H/Ascend 3H/Keep9H )
No malfuction and
performance deterioation
HH-35
4
Transport
condition
Vibration 1
10~500Hz,10 ms-2,1gn,
0.075mm x2 /XYZ
No malfuction and
performance deterioation
HH-35
5 Transport bump
10g,6ms,halfsine,1000times/
±XYZ
No malfuction and
performance deterioation
HH-35
6 Transport shock
300ms-
2,30gn,6ms,halfsine,1times
/±XYZ
No malfuction and
performance deterioation
HH-35
7
Transport
condition
Vibration 2
Internal Regulation
15~60Hz, Random Acceleration,
Displacement 1.0mm, 3 Cylces
1Hz per min, XY Axis * 6 Face
No malfuction and
performance deterioation
HH-35
8
Transport
condition
Free Fall
1.0m Free Fall, Bottom Face, 4
Edge, 4 Corner, 2 Cycle
No malfuction and
performance deterioation
HH-35
9
Transport
condition
Temperature
Shock
ISO-9022-15-04-1 (70±2) ℃ / (-
55±2) ℃ 4H 5CYCLE
No malfuction and
performance deterioation
HH-35
10
Continuous
Power On/Off &
slow
temperature
change
(-10±2)℃ 4H ~(55±2)℃ 4H,
10CYCLE On 2.5min / Off 0.5min
Input Voltage
90/110/132/180/220/264V
50Hz/60Hz, Each 40 times, total
480times
No malfuction and
performance deterioation
HH-34
11
Discharge
Power On/Off &
slow
temperature
change
(-10±2)℃ 4H ~(55±2)℃ 4H,
10CYCLE On 1min / Off 9min
Input Voltage
90/110/132/180/220/264V
50Hz/60Hz, Each 40 times,
total 480times
No malfuction and
performance deterioation
HH-34
12
IMPULSE
NOISE
Line
2Kv @ Common Mode
2Kv @ Normal Mode
Criteria A
HH-06
HH-07
13 IMPULSE ±500V 5sec per point Performance Criteria A @ HH-06
