NOISE
Radiation
±2,000V 5sec per point ±500V ; Criteria C @ ±2kV HH-07
14
Voltage
DIP & Short
Interruption
IEC 61000-4-11
100%, 60%, 30%, 0.5T, 5T, 25T
90/110/132/180/220/264V
90/110/132/180/220/264V
50Hz/60Hz
Criteria A HH-06
15 Harmonic
IEC 61000-4-13
Flat Curve Class 1
Over Swing Class 1
AC 90/110/132/180/220/264V
50Hz/60Hz
Criteria A HH-06
16
Voltage
Variation
IEC 61000-4-11
40%UT- Reduce 2sec, Stable
1sec Increase 2sec 0% UT -
Reduce 2sec, Stable 1sec
Increase 2sec
90/110/132/180/220/264V
50Hz/60Hz
Criteria C HH-06
17
Thermal
Derating
Internal Regulation Continuous
Operating Mode @ 40℃,
Recording the main part
thermocouple
Derating ≤80%
18
ESD
Air / Contact /
Indirect
IEC 61000-4-2
Air ±15kV, Contact ±8kV
Indirect ±8kV
Meet the Class A HH-06
19
Leakage Current
Test
1. Earth leakage current :
2. Applied part leakage current :
3. Patient applied part
leakagecurrent :
1. N.C ≤ 5mA , S.F.C ≤
10mA
2. N.C ≤ 0.1mA , S.F.C ≤
0.5mA
3. N.C ≤ 0.1mA , S.F.C ≤
0.5mA
HH-02
20
Dielectric
strength Test
Primary to P.E : 1.5 kVac / 60s
Primary to Secondary : 4 kVac /
60s
No breakdown HH-05
21
Earthing
resistance Test
IEC/EN: 25A, 5s
UL/C-UL: 40A, 120s
≤ 0.1 Ω HH-05
13. Drawings
Document Name Document Number Revision no
First issued
date
Revision
issued date
Drawing List with CCL HQI-M-FC1-001
△
2
R1
2019-07-18
△
2
2020-05-14
