Hydac HMG 4000 User Manual

Technical specifications HMG 4000
Edition 2016-03-08 - V01 R04 [113] Part No.: 669950
18 Technical data
18.1 Input channels
18.1.1 Analogue inputs
Quantity
8 channels via eight M12x1 Ultra Lock flanged jacks (5-pin)
Description
Channel A - Channel H
Input signals
HYDAC HSI analogue sensors
HYDAC HSI SMART sensors
Voltage ranges: 0 - 50 V, 0 - 10 V, 0 - 4.5 V, -10 - +10 V
Current ranges: 0 - 20 mA
PT 100 / PT 1000 (channel H only)
Resolution
12 bit
Accuracy
≤ ± 0.1 % of respective input range end value
(Examples:
Sensor signal = 0 - 5 V → Input range 0 - 10 V
Sensor signal = 0 - 15 V → Input range 0 - 50 V)
≤ ± 1 % with PT 100 / PT 1000
18.1.2 Digital inputs
Quantity
2 channels via one M12x1 Ultra Lock flanged jack (5-pin)
Description
Channel I, J
Input signals
Digital status (high / low)
Frequency (0.01... 30,000 Hz)
PWM duty cycle
Level
Switching threshold / switch-back threshold: 2 V / 1 V
Max input voltage: 50 V
Accuracy
≤ ± 0.1 %
18.1.3 CAN
Quantity
28 channels via one M12x1 Ultra Lock flanged jack (5-pin)
Description
Channel K1 - K28
Input signals
HYDAC HCSI sensors
CAN
J1939
CANopen PDO
CANopen SDO
Baud rate
10 kbit/s … 1 Mbit/s
Accuracy
≤ ± 0.1 %
