Hydac RFCS Series User Manual

Installation and maintenance manual
H.I.B Hydac International Page 30 of 36
Version: G/DV
Date: 11.01.2023
WARNING
Behind the cover, there are hot system parts with sharp edges. When
the covers are removed for maintenance or repair work, make sure not
to touch these components!
Pos.
Description
1.
Push the filter
upwards
2.
Pull filter away from
the cooler
Schematic diagrams G4,G5,G6,G7,G8,D3,D4
Schematic diagrams G0, D2, D5
Pos.
Description
1.
Slide the filter upwards
Pos.
Description
1.
Remove the screws (2x)
2.
Remove cover and remove filter mat
