THE BASIC REVERSE OSMOSIS SYSTEM cont.
1.5" Air Gap Required
Inlet-1/2" White
Drain - 3/8" Black Purified Water - 3/8" Blue
Feed Water Valve
Cold Water Line Only
Feed Pressure
Gauge
Optional Pre-Evolution
™
Pre-Filter
Pure Water Storage Tank
To Point of Use
Optional 3/8” Float Valve
Typical Light Commercial Installation with Storage Tank
