Hydrofarm Autopilot ECLIPSE F60 - LED Display & Control Surface; Control Surface Layout

FUNCTION KNOBS
LED DISPLAY & CONTROL SURFACE
(
RH% & TEMP LOCK
)
(
TIMER OUTPUT
)
(
ERROR LEDS
)
(
POWER INPUT
)
(
COOLING OUTPUT
)
(
TIMER SETTING
)
(
ON/OFF BREAKER
)
Click function knob, turn to
set, press again to confirm
Press both function knobs:
Min/Max recall, display
clock
Press both function knobs
for 3 seconds to set clock/
Switch °F/°C
(
TIMER MODE
)
(
TEMP SETTING
)
(
TEMP DEADBAND
)
(
HUMIDITY MODE
)
(
HUMIDITY OUTPUT
)
(
HEATING OUTPUT
)
(
HUMIDITY SETTING
)
(
SENSOR CORD
)
(
PHOTOCELL
)
(
STATUS
)
