Figure 2
BLUE
BROWN
YELLOW+GREEN
Wiring and safety of the oven
In case of any damage to the
feeder cable, please call the Authorised
Service agent. The cable be replaced by
the Authorised Service agent.
The instructions given below must be followed
without fail during wiring :
IMPORTANT - The earthing cable must be
connected via the screw with the earthing
mark. Supply cable connection must be as
shown in Figure 2. If there is no earthed outlet
conforming to regulations in the installation
environment, call the Authorised Service
immediately.
IMPORTANT - The earthed outlet must be in
close vicinity of the appliance. Never use an
extension cord.
IMPORTANT - The supply cable should not
contact the products hot surface.
IMPORTANT -
must
IMPORTANT - Wiring of the appliance must
be performed by the Authorized Service agent.
H05VV-F type supply cable must be used.
IMPORTANT - Faulty wiring may damage the
appliance. Such damage will not be covered
under the warranty.
IMPORTANT - The appliance is designed to
connect to 220-240V~ electricty supply if your
household supply is different than the value
given above, call the Authorized Service
immediately.
IMPORTANT - The Manufacturer declares that
it bears no responsibility whatsover for any
kind of damage and loss arising from not
complying with these safety instructions.
7
Installation
Customer Helpline 0845 600 4632
Electrical connection
