10 Field Service Bulletin
HyPro2000 — HT2000 TORCH UPGRADE
9. Slide the coolant hose insulator over the fi ttings.
10. Secure the coolant hose insulator in place by wrapping electrical tape around the lead set.
11. Slide the torch mounting sleeve over the fi ttings and screw it onto the torch quick-disconnect receptacle.
Torch mounting sleeve
