 Installation‐ElectricalSupplyMains 
18

Figure6:ChillerInternalAccess
6.5 ElectricalSupplyMains
6.5.1 MainsPowerRequiremen ts
EnsurethatthesupplypowerissufficienttomeetthechillerpowerrequirementsdefinedinTable5and
conformstoalllocalandnationalelectricalcodes:
Table5:ChillerElectricalSupplyPowerRequirements
Criterion 50Hz 60Hz
Voltage[V] 380‐415V±10% 460‐480V±10%
Phase 3
FLA[A] 23
MCA[A] 26
MOPD[A] 40
SCCR[kA] 12
Note:Thisinformationcanalsobefoundonthechiller’sdatatag,
locatedonthefrontoftheelectricalenclosure(refertoFigure7,
datatagnotshown).
 
AIRFILTERLATCH DOORLATCH
UPPERBLOCKER
2XUPPERBLOCKERLATCH 
2XSIDEBLOCKERLATCH
DOORHANDLE
AIRFILTER
SIDEBLOCKERS
DOOR
