MODEL DESCRIPTION
18
ITEM
NO.
ITEM FUNCTION
13 Range Lever
(Manual
Transmission)
(S135--155XL)
The range lever is located to the left of the steering column. This lever controls
the three speed ranges of the S135--155XL manual transmission.
14 Range Lever
(Powershift
Transmission)
(S135--155XL
Only)
The range lever for the transmission is to the left of the steering column. The
range lever controls the two speed ranges of the powershift transmission.
15 Lift/Lower
Control
Lever
The lift/lower control lever is the first lever to the right of the steering wheel. Pull
backward on the control lever to raise the carriage and forks. Push the control
lever forward to lower the carriage and forks.
16 T ilt
Control
Lever
The tilt control lever is on the right of the lift/lower control lever. Push the control
lever forward to tilt the upright and forks forward. Pull backward on the control
lever to tilt the upright and forks backward.
