MODEL DESCRIPTION
19
ITEM
NO.
ITEM FUNCTION
17 Control Lever
or Auxiliary
Hydraulic Functions
See TABLE 3.
The control lever for auxiliary hydraulic functions is installed to the right of the
tilt control lever. This control lever actuates a control spool in the control valve
for a single function attachment and two control spools for a two--function
attachment.
Single Function Operation: The lever is spring--loaded to the left and must be
pushed to the right before operating the auxiliary function.
Two Function Operation: The lever is spring--loaded to the left and will
operate one auxiliary function in this position. The lever must be pushed to the
right before operating the other auxiliary function.
