6
2. Product Overview
2.1 Product Layout
Front Panel
Aviation Port
Answer Key
(programmable)
End Key
(programmable)
OK/Menu Key Back/Zone Key On-Off Key
LED Indicator
Volume Key
Channel/Navigation Key
Emergency Key
(programmable)
Rear Panel
RF Antenna Connector
Power Inlet
Accessory Connector GPS Antenna Connector
The GPS antenna connector is only used to install the GNSS antenna on radios with the Location feature.
