Maintenance
32
7
Front windshield wiper b
lade
1.
Raise the wiper ar
m.
2.
Lift up the wiper blade clip
.
Then pull
down the b
lade assembly and remov
e
it.
3.
Install the new b
lade assembly in the
re
verse order of remo
val.
OHM078059
O
YF079061
O
YF079062
CA
UTION
Do not allow the wiper arm to fall
against the windshield,
since it may
chip or crac
k the windshield.
YF HMA 7.QXP 11/25/2009 1:47 PM Page 32
319
321
