6-24
PUMP 03
Lift and remove end cover.
(8)
PUMP 04
Carefully remove gear housing and place
on work bench. Make sure the rear
bearing block remains on the drive and
idler shafts.
(9)
PUMP 05
Remove rear bearing block from drive and
idler shafts.
(10)
PUMP 06
Remove idler shaft from bearing block.
(11)
