8-1
GROUP 1 STRUCTURE
SECTION 8 MAST
1. 2 STAGE MAST(V MAST)
CARRIAGE
LIFT CYLINDER
5
2
6
7
8
12
13
TILT CYLINDER
1
4
3
9
10
11
20D7MS01
1 Outer mast
2 Inner mast
3 Roller
4 Shim(0.5, 1.0t)
5 Chain
6 Anchor bolt
7 Chain wheel bearing
8 Retaining ring
9 Tilt cylinder pin
10 Trunnion cap
11 Bushing
12 Roller
13 Shim(0.5, 1.0t)
