Maintenance
Front turn signal bulb
Follow steps 1 to 5 from previous page.
6.Remove the socket from the assembly
by turning the socket counterclockwise
until the tabs on the socket align with
the slots on the assembly.
7.Remove the bulb from the socket by
pressing it in and rotating it counter-
clockwise until the tabs on the bulb
align with the slots in the socket. Pull
the bulb out of the socket.
8.Insert a new bulb by inserting it into the
socket and rotating it until it locks into
place.
9.Install the socket in the assembly by
aligning the tabs on the socket with the
slots in the assembly. Push the socket
into the assembly and turn the socket
clockwise.
10.Reinstall the light assembly to the
body of the vehicle.
Front side marker
Follow steps 1 to 5 from previous page.
6. Remove the socket from the assembly
by turning the socket counterclockwise
until the tabs on the socket align with
the slots on the assembly.
7. Remove the bulb from the socket by
pulling out the bulb.
8. Insert a new bulb.
9. Install the socket in the assembly by
aligning the tabs on the socket with the
slots in the assembly. Push the socket
into the assembly and turn the socket
clockwise.
10. Reinstall the light assembly to the
body of the vehicle.
Fog light bulbs (if equipped)
If the light bulb is not operating, have the
vehicle checked by an authorized
HYUNDAI dealer.
OMD070055N
Side marker
Turn signal
