Hyundai HY2000SI User Manual

29.
EN
5. With the engine in a level position, add oil to the upper level
mark (Refer to Fig. 5.4)
Fig. 5.4
6. Reinstall the oil ller cap/dipstick securely.
7. Reinstall the maintenance cover and tighten the cover screws
securely.
5.5: Spark Plug Service
1. Remove the top screw and the top maintenance cover (Refer to
Fig. 5.5 for HY1000Si and Fig. 5.6 for HY2000Si)
Fig. 5.5 Fig. 5.6
2. Remove the ignition coil (Refer to Fig. 5.7 for HY1000Si and Fig.
A
A
L
L/2
Oil ller cap
Lower limit
Upper limit
Dipstick
Top maintenance cover
Screw
Screw
Top maintenance cover

Hyundai HY2000SI Specifications

General

Starting System	Recoil
Engine Displacement	79cc
Voltage	230V
Frequency	50Hz
Engine Type	OHV
Rated Power	1.6 kW
Max Power	2000 watts
Run Time	8 hours @ 50% load
Weight	21 kg
