5.3. Unpack the Pressure Washer
5.3.1. Remove the parts bag, accessories, and inserts included with
pressure washer.
5.3.2. Remove machine from box.
5.3.3. Ensure you have all included items prior to assembly.
5.4. Attach Handle
5.4.1. Place handle (A) onto handle supports (B) connected to main
unit. Make sure holes (C) in handle align with holes on handle
supports.
5.4.2.
5.5. NOTE It may be necessary to move the handle supports from side to side in order to
align the handle so it will slide over the handle supports.
5.6. Insert carriage bolts through holes from outside of unit and attach a plastic knob
from inside of unit. Tighten by hand.
5.7. Insert multi coloured quick connect spray tips and other supplied accessories in
spaces provided on handle.
