7.4. Choose desired nozzle, pull back nozzle extension collar, insert nozzle and
release collar. Tug on nozzle to make sure it is securely in place. See Nozzle
Selection Section.
7.5. Uncoil high pressure hose and attach quick connect end of hose to base of
spray gun. Pull down on collar of quick connect, slide onto spray gun and let
go of collar. Tug on hose to be sure of tight connection. Some models may
use a threaded hose connector.
7.6. WARNING The high pressure stream of water that this equipment produces
can cut through skin and its underlying tissues, leading to serious injury and
possible amputation.
7.6.1. NEVER connect high pressure hose to nozzle extension.
7.6.2. Keep high pressure hose connected to pump and spray gun while system is
pressurized.
7.6.3. Always be certain spray gun, nozzles and accessories are correctly attached.
7.7. attach other end of high pressure hose to high pressure outlet (A) on pump.
Pull down on collar of quick connect, slide onto pump and let go of collar.
Pull on hose to be sure of tight connection. *Some models may use a
threaded hose connector.
7.8. NOTE Pump Uses SAE 15W 40 Oil.
7.9. Turn Water Supply on, point gun in a safe direction and squeeze the trigger
to purge the pump of air and debris. Do this for at least 30 seconds.
