1
FEATURES OF YOUR HYUNDAI
97
HEATING CONTROLS
B690A01O-AAT
For normal heating operation, set the air flow
control to the floor ( ) position. (The "Fresh"
mode will be activated.)
For faster heating, the air intake control switch
should be set in the recirculate ( ) position.
If the windows fog up, set the air flow control to
the defrost ( ) position (The A/C will turn on
automatically and "Fresh" mode will be acti-
vated.)
For maximum heat, move the temperature con-
trol to "Warm".
B690A01O-1
B670E02A-AAT
Temperature Control
This control is used to adjust the degree of
heating or cooling desired.
B670E01O
Cool Warm
B670D07O
OFF-Level
Air is discharged through the windshield de-
froster nozzle, side defroster nozzle and side
ventilator.
NOTE:
If the air flow control is off, the air intake
control is set to the fresh mode automati-
cally.
smhma-1b.p65 5/25/2005, 2:23 PM97
