FEATURES AND CONTROLS
SANTA FE
1615
HYUNDAI
AUTOMATIC CLIMATE CONTROL
NOTE:
To reduce the tendency of the glass fogging and also to improve visibility,
keep the interior surface of the windshield clean by wiping it with a clean
cloth and glass cleaner. In addition, select air intake control to the
outside (fresh) air position whenever possible while operating the vehicle.
7
Passenger's Temperature Control Knob
8
AUTO (Automatic Control) Button
9
OFF Button
10
Air Conditioning Button
11
Mode Selection Button
12
SYNC Button
1
Driver’s Temperature Control Knob
2
Front Windshield Defrost Button
3
Rear Window Defrost Button
4
Fan Speed Control Knob
5
Air Intake Control Button (Recirculated air)
6
Air Intake Control Button (Outside air)
AIR INTAKE CONTROL
Changes the direction of the air flow as following:
MODE SELECTION
SYSTEM OFF
Pressing the OFF button will
place the system to the OFF
mode.
• Climate control fan will turn off.
• Outside (fresh) air position will
be selected.
• Vented air will be at last set
temperature.
AUTOMATIC HEATING /
AIR CONDITIONING
The modes, fan speeds,
air intake and air
conditioning will be
controlled automatically
by the temperature
setting you select.
DEFOGGING
/
DEFROSTING
HEATED STEERING WHEEL BUTTON
8
9
10
11
3
4
1
5
6
7
12
2
Outside (fresh) air position
(LED off)
Recirculated air position
(LED on)
It is recommended to use the AUTO
function with 72°F temperature set
point for optimum comfort and
efficiency. Adjust the temperature
as desired
3. Set the fan speed to
the medium setting.
2. Set the temperature
control to the
warmest setting.
1. Press the front
windshield defroster
button.
